079103 PTO side mount, 2 gear constant mesh, pneumatic
MERCEDES
PTO MB G2/24-5 SIDE, 2 GEAR, PNEUMATIC. Continuous Torque (Nm): 200 Intermittent Torque (Nm): 280 Max. Power (kW):21 Mou...
Power Take-off two gears, ratio 1:1,32 to connect Iso 4 bolts pumps. Pneumatic shifting. Mounting on rear 7 bolts-window of the Gearbox. Optional: Passing contact switch
| SKU | Type of mount | Output type | Peso (kg) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|---|---|
| 078202 | Standard | Flange | - | - | - | - |
| 078203 | Standard | Pump (DIN 5462) | - | - | - | - |
| 0710202 | Constant Mesh | Flange | - | - | - | - |
| 0710203 | Constant Mesh | Pump (DIN 5462) | - | - | - | - |
Power Take-off two gears, ratio 1:1,32 to connect Iso 4 bolts pumps. Pneumatic shifting. Mounting on rear 7 bolts-window of the Gearbox. Optional: Passing contact switch
| Atributo | Valor |
|---|---|
| Continuous Torque (Nm) | 300 |
| Intermittent Torque (Nm) | 420 |
| Power (1000 r.p.m.) | 42 C.V // 32 kW |
| Mounting Position | Rear |
| Sentido de giro de la bomba | R (Clockwise) |
| Weight (Kg) | 14.5 |
| Note A | Air connection, thread 1/8” BSP |
| Note B | Oil drain plug |
| Note C | Rotation |
| Note D | Pressure switch. P/N 100070018 |
| Note E | Passing contact switch. P/N 9024999 |
| Gearbox | G100, G140-8 |
| Type of mount | Standard, Constant Mesh |
| Output type | Flange, Pump (DIN 5462) |
