034403 PTO side mount, 2 gear mechanical shifting, 1:1,31
NISSAN
PTO TURNER M5-25 E,F.SIDE.MECHANIC Continuous Torque (Nm): 175 Intermittent Torque (Nm): 250 Max. Power (kW):19 Mounting...
Power Take-off two gears, constant mesh, to connect ISO 4 bolts pumps. Pneumatic shifting, mounting on left side of the Gearbox. Optional: Passing contact switch. Engine to PTO ratio MPS 62A, MPS 62B MPS 63B 1: 1,44 1: 1,73 Note A Air connection, thread 1/4” BSP Note B Rotation Note C Passing contact swith. P/N […]
| SKU | Output type | Peso (kg) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|---|
| 039403 | Pump (DIN 5462) | - | - | - | - |
| 039402 | Flange | - | - | - | - |
Power Take-off two gears, constant mesh, to connect ISO 4 bolts pumps. Pneumatic shifting, mounting on left side of the Gearbox. Optional: Passing contact switch.
| Atributo | Valor |
|---|---|
| Continuous Torque (Nm) | 300 |
| Intermittent Torque (Nm) | 420 |
| Power (1000 r.p.m.) | 42 C.V // 32 kW |
| Mounting Position | Top |
| Sentido de giro de la bomba | Clockwise |
| Weight (Kg) | 15 |
| Gearbox | MPS-62A, MPS-62B, MPS-63B |
| Output type | Flange, Pump (DIN 5462) |
