7028804 Adapter Kit for D11
ENGINE PTO
Adapter Kit for Volvo D11 series engines to connect ISO 4 bolts pumps.
The Power take-off’s for the gearbox R1000, R1400, R1700, SR1400, SR1700, SR1900, SR2000 with or without retarder consists of this adapter kit with flange and the take-off base (ZF). ENGINE TO PTO RATIO Gearbox High Normal R1000, R1400, R1700, VT1708, VT2009B 1: 0,700 SR1400, SR1700,SR1900 1: 0,880 1: 0,700 SR2000 1: 0,820 1: 0,650 SRO2400 […]
| SKU | Type | Peso (kg) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|---|
| 110104 | Normal | - | - | - | - |
| 110304 | Retarder | - | - | - | - |
| 110404 | Normal + Flange | - | - | - | - |
| 110704 | Retarder + Flange | - | - | - | - |
The Power take-off’s for the gearbox R1000, R1400, R1700, SR1400, SR1700, SR1900, SR2000 with or without retarder consists of this adapter kit with flange and the take-off base (ZF).
| Atributo | Valor |
|---|---|
| Continuous Torque (Nm) | 600 |
| Intermittent Torque (Nm) | 840 |
| Power (1000 r.p.m.) | 85 C.V // 63 kW |
| Mounting Position | Rear |
| Weight (Kg) | 5 |
| Gearbox | VTO-2514B, R-1000, VTO-2814B, R-1400, R-1700, SR-1400, SR-1700, SR-1900, SR-2000, SRO-2400, VT-1708, VT-2009B, VT-2014B, VT-2214B, VT-2412B, VT-2514B, VTO-2214B |
| Type | Normal, Retarder, Normal + Flange, Retarder + Flange |
Adapter Kit for Volvo D11 series engines to connect ISO 4 bolts pumps.
