Twin flow axial piston pumps offers two different flows. In addition, we find several advantages such as lower weight or standar system solutions. BZT are available in ISO and SAE version. BZT Technical Datasheet
| SKU | Type | Peso (kg) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|---|
| 5040206 | BZT 51+51 | 16.50 | 246.00 | 133.00 | 148.00 |
| 5040306 | BZT 61+41 | 16.50 | 246.00 | 133.00 | 148.00 |
Twin flow axial piston pumps offers two different flows. In addition, we find several advantages such as lower weight or standar system solutions. BZT are available in ISO and SAE version.
| Atributo | Valor |
|---|---|
| Tamaño de la bomba | 40, 50, 60 |
| Displacement (cm3/rev) QD | 50 (BZT 51+51), 60 (BZT 61+41) |
| Displacement (cm3/rev) QE | 50 (BZT 51+51), 40 (BZT 61+41) |
| Maximum peak pressure (P3) (bar) | 350 |
| Operating pressure (kg/cm2) max. cont. | 250 |
| Operating Speed (r.p.m) max. | 1300 |
| Operating Speed (r.p.m) max. cont. | 1100 |
| Input power (CV) max. | 85 |
| Input power (CV) max. cont. | 57 |
| Input Pressure (recommended) | 0.7÷ 3 bar (abs) |
| Temperatures | From -25ºC to 80ºC |
| Recommended Oil | The specification of the fluid must conform to DIN 51524 / 51525 (type HLP). |
| Viscosity recommended | De 12 ÷ 100 mm2/s (cST) |
| Viscosity allowed | 750 mm2/s (cST) |
| Note A | Oil Inlet, thread BSP 1 1/2” |
| Note B | Drain hole (Between shaft-seals) |
| Note C | Oil drain plug |
| Note D | Oil outlet (first flow), thread BSP 3/4” |
| Note E | Oil outlet (second flow), thread BSP 3/4” |
| Type | BZT 51+51, BZT 61+41 |
