039502 Side Mount-Pneumatic
NISSAN
Power Take-off one gear, constant mesh, to connect Iso 4 bolts pumps. Pneumatic shifting, mounting on left side of the G...
Power Take-off one gear, constant mesh, to connect ISO 4 bolts pumps. Pneumatic shifting, mounting on left side of the Gearbox. Optional: Passing contact switch. Engine to PTO ratio High Normal 1: 0,914 1: 0,742 Note A Air connection, thread 1/4” BSP Note B Rotation Note C Passing contact swith. P/N 100070001
| SKU | Output type | Peso (kg) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|---|
| 035103 | Pump (ISO) | - | - | - | - |
| 035102 | Flange | - | - | - | - |
Power Take-off one gear, constant mesh, to connect ISO 4 bolts pumps. Pneumatic shifting, mounting on left side of the Gearbox. Optional: Passing contact switch.
| Atributo | Valor |
|---|---|
| Continuous Torque (Nm) | 300 |
| Intermittent Torque (Nm) | 420 |
| Power (1000 r.p.m.) | 42 C.V // 32 kW |
| Mounting Position | Top |
| Sentido de giro de la bomba | Clockwise |
| Weight (Kg) | 12,3 |
| Gearbox | MRT-21A, ART-20A, ART-21A, ART-23A, ART-25B, MRT-20A, MRT-23A, MRT-25B |
| Output type | Flange, Pump (ISO) |
