7028804 Adapter Kit for D11
ENGINE PTO
Adapter Kit for Volvo D11 series engines to connect ISO 4 bolts pumps.
Power Take-off two gears, mounting on rear 4 bolts-window of the Gearbox. Pneumatic shifting, to connect Iso 4 bolts pumps. NOTES Note A Air connection, thread M12 – 1.5 Note B Oil drain plug Note C Rotation
| SKU | Output type | Peso (kg) | A (cm) | B (cm) | C (cm) |
|---|---|---|---|---|---|
| 110203 | Pump (DIN 5462) | - | - | - | - |
| 110102 | Flange | - | - | - | - |
Power Take-off two gears, mounting on rear 4 bolts-window of the Gearbox. Pneumatic shifting, to connect Iso 4 bolts pumps.
| Atributo | Valor |
|---|---|
| Continuous Torque (Nm) | 300 |
| Intermittent Torque (Nm) | 420 |
| Power (1000 r.p.m.) | 42 C.V // 32 kW |
| Mounting Position | Rear |
| Sentido de giro de la bomba | Clockwise |
| Weight (Kg) | 9,3 |
| Engine to PTO ratio | 1: 0,760 |
| Gearbox | SR-52, R-52, R-51 |
| Output type | Flange, Pump (DIN 5462) |
Adapter Kit for Volvo D11 series engines to connect ISO 4 bolts pumps.
